STG12 CAN Bus Pressure Transmitter

The STG12 CAN Bus Pressure Transmitter is designed with a high-precision silicon sensing element and advanced signal conditioning circuitry integrated within a robust stainless steel housing. It converts pressure signals into stable and reliable CANopen digital output, ensuring accurate performance in demanding industrial environments. With its compact structure, excellent long-term stability, and IP67 protection, the STG12 is ideal for a wide range of applications including construction machinery, heavy-duty vehicles, hydraulic systems, and industrial automation.

1. Key Features

Compact design with all-stainless-steel construction and multiple pressure connection options
Ingress protection rating IP67
CANopen bus communication output
Reverse polarity protection and transient overcurrent / overvoltage protection
Compliant with EMC protection requirements

2. Technical Specifications

General Electrical Data

Pressure Range	0.1 to 1000bar
Pressure Type	Gauge / Absolute
Output Signal	CANopen
Supply Voltage	5.5–30VDC

Performance Specifications

Accuracy	±0.5%F.S.,±0.2%F.S.
Long-term Stability	≤±0.05%F.S./year
Overpressure	150%F.S.
Burst Pressure	300%F.S.
Temperature Compensation Range(accuracy maintained within this range)	-35 to 100 °C
Operating temperature range	−40 to +125°C
Storage temperature range	−40 to +125°C
Media Temperature Range	-40°C to +125°C

3. Applications

Heavy-duty trucks
Wind power hydraulic systems
Construction machinery
High-precision control
Semiconductor equipment
Other industrial applications

4. Selection Guide

Pressure Sensor Selection Key Points: Confirm the measuring range, match the output signal, ensure media compatibility, select the appropriate mounting interface, and define the accuracy requirements.

5. FAQ (Frequently Asked Questions)

Q1: What are the manufacturer’s advantages and customization options for the STG12 CAN Bus Pressure Transmitter?

With over 10 years of industrial pressure Transmitter experience, the STG12 CAN Bus Pressure Transmitter offers OEM/ODM customization, strict quality control, and fast global shipping support.

Q2: What are the typical applications of the STG12 CAN Bus Pressure Transmitter?

The STG12 CAN Bus Pressure Transmitter is ideal for heavy-duty trucks, construction machinery, wind power hydraulics, industrial automation, semiconductor equipment, and precision control applications.

Q3: What is the accuracy and long-term stability of the STG12 CAN Bus Pressure Transmitter?

The STG12 CAN Bus Pressure Transmitter offers high accuracy up to ±0.5% F.S or ±0.2% F.S, with long-term stability of ≤ ±0.05% F.S/year, ensuring reliable measurements over extended periods.

Q4: What pressure range does the STG12 CAN Bus Pressure Transmitter support?

The STG12 CAN Bus Pressure Transmitter supports a wide pressure range from 0.1 to 1000 bar, suitable for various industrial pressure measurement applications, with multiple selectable ranges.

Q5: What is the STG12 CAN Bus Pressure Transmitter?

The STG12 CAN Bus Pressure Transmitter is a high-precision industrial Transmitter featuring a silicon sensing element and advanced signal conditioning, converting pressure signals into CANopen digital bus output. It is ideal for construction machinery, heavy-duty trucks, hydraulic systems, and industrial automation applications.

6. Related Products

7. Contact Us

📧 Email: sales@yatansensor.com, support@yatansensor.com

💬 WhatsApp:+86 185 1660 2370

8. Model Selection / Ordering Code

Please specify the full ordering code when requesting a quotation.

        Model - Range - Output - Accuracy - Electrical Interface - Connector - Cable Length - Supply Voltage

        Example:
        STG12 - 0~100bar - 4-20mA - 0.5%- G1/4 - M12 - 1m - 24V
