STG34 Union Pressure Transmitter
The STG34 union-type pressure transmitter is a high-performance sensing device combining advanced international technology with local manufacturing expertise, specifically designed for oil drilling and high-pressure applications. It utilizes a high-precision imported strain gauge with high resistance and a specialized diaphragm structure, offering a measuring range up to 150 MPa. The transmitter features excellent resistance to shock, vibration, and corrosion, ensuring reliable operation in harsh environments. Its all-stainless-steel housing with anti-clogging design guarantees long-term stability and durability. The device supports multiple output signals, including 4-20mA, 0-5V, and 0-10V, making it compatible with various industrial control systems. Widely used in fracturing trucks, cementing units, and petrochemical high-pressure systems, it serves as an ideal replacement for imported products. Compliant with IEC standards for EMC, vibration, and shock resistance, the STG34 delivers high reliability and accuracy with a comprehensive accuracy of 0.5% F.S and excellent long-term stability. It operates reliably across a wide temperature range of -40°C to 125°C, making it a cost-effective and robust solution for industrial pressure measurement applications.
